LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4

    Buy cheap LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4 from wholesalers

    Buy cheap LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4 from wholesalers
    • Buy cheap LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4 from wholesalers
    • Buy cheap LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4 from wholesalers

    LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4

    Ask Lasest Price
    Brand Name : Sunica
    Model Number : -
    Price : $0.99/pcs-$120/pcs
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 5-15
    • Product Details
    • Company Profile

    LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4

    16s 48v Lithium battery bms board 100a16s LFP bms 20amp 48v 16s bms lifepo4

    * Support overcharge protection, over discharge protection, over current protection and short circuit protection.

    * This protection board is suitable for 16 series of 48V 18650 Li-ion batteries.

    * This protection board is suitable for Li-ion battery


    ModelXLH-EVP-P100S16XLH-ESS-P200S16
    Electric coreLithium iron phosphate / ternary / lithium titanate
    Number of core stringsAdaptive 15 string / 16 string
    Individual voltage collection accuracy±5mV
    Total battery voltage collection accuracy±0.5%@FSR
    Current acquisition accuracy1%@FSR
    Core temperature acquisition channel4 Channel
    Max charge current100A200A
    Max discharge current100A200A
    Capacitive load60000uF
    Operating temperature range-30℃~80℃
    Recommended working temperature-30℃~70℃
    Storage conditionsTemperature: -20°C ~ + 45°C
    Humidity:5%-95%RH
    CoolingNatural cooling
    BMS BOXW400*D260*H150mm
    PACK safety certification PackOEM IEC62619/CE/RCM/UL1973/CEC
    Communication portCAN2.0B*2CH;RS485*1CH;Bluetooth,4G
    Dry contact2Channel
    Number of supported cascade10PACKs
    high voltage PACK finished parallel connection10PACKs
    Altitude3000m
    Self power consumptionWork<50mA Hibernation<200uA
    Heating ModuleMAX500W
    LEDRun light:1pcs,Green;
    Fault light:1cs,Red;
    SOC:4pcs,Bule

    LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4


    LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4

    LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4
    LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4LFP 20amp Lifepo4 Battery BMS 48v 100a Lithium Battery 16s Lifepo4

    We offer:

    1) Good quality control

    2) High flexibility in design and development

    3) Professional business team communication.

    4) Competitive price


    Q&A
    Q1: Are you factory?
    A1: Yes, sunica battery is in DongGuan, Guangdong. Welcome to visit us at anytime.
    Q2: What’s the warranty of your battery?
    A2: 15months being valid from the date of production.
    Q3: What is MOQ? A3: No MOQ for new customers. Q4: Can we have the customize design?
    A3: OEM/ODM service are available.
