Stacked Energy Storage 10kw Solar Battery Lighter 200Ah UPS Battery Unit

Product Categories

Liren Design (Dongguan) Co., Ltd.

Contact Now

Stacked Energy Storage 10kw Solar Battery Lighter 200Ah UPS Battery Unit

Ask Lasest Price
Brand Name :	Sunica
Model Number :	01
Certification :	ce
Price :	USD 400- 10000 / pieces
Payment Terms :	T/T, L/C, D/A, D/P
Supply Ability :	100000 packs per year
Delivery Time :	7-20 working days

Add to Cart

Product Details
Company Profile

Stacked Energy Storage 10kw Solar Battery Lighter 200Ah UPS Battery Unit

10KW Stacked Energy Storage 200Ah UPS Battery Unit for Energy Storage System

Model	TP48200(5U)
Nominal voltage(V)	51.2
Nominal capacity(Ah)	200
Nominal energy (Wh)	10240
Maximum charging voltage(V)	58.4
Max. charging current(A)	150
Charging method	CC/CV
Max Continuous Discharge Current(A)	150
Maximum peak discharge current @10sec(A)	160
Max. load power(W)	7000
Discharge cut-off voltage(V)	40
Charging temperature(℃)	0~+50
Discharge temperature(℃)	-20~+60
Operating humidity:	<95%R.H
Operating humidityCycle times(25℃,0.5C,80%DOD)	>2000
Battery combination mode	16S1P
Terminal specification	DZT-2P-200A*2
Protection class	IP54
Dimension(mm)	442480177 mm
Reference weight(kg)	80
Communication mode	232/485/CAN

This Lithium-Ion Battery has a long lifespan of 6 000 cycles at 80%
depth of discharge at 25°C. In addition, the batteries can support
up to 15 batteries in parallel for expansion. The batteries are set
to sleep mode (off) during transportation and storage to reduce
loss of capacity. has the following remarkable characteristics:

mounted lifepo4 battery

About our Lifepo4 battery cell:
As a over 10-year-old store engaged in the battery business, we are
responsible for our customers and our brand.Using only A grade cells, the cycle life can up to 6000 times: 50ah
/ 60ah / 100ah/ 200ah / 230ah / 280ah...
1. Our batteries are the primary source of supply from the original
cells manufacturer, battery cells are paired and distributed before
outgoing, and can be assembled directly.
2. Through a number of certification and testing, quality
assurance.
3. There are two types of pouch cells and prismatic cells. The
pouch cells: lighter, cheaper, and easy to customized in special
sizes. The prismatic cells: not easily deformed , stable
performance, mature market, more popular at present.

FAQ:Q.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.Q. What about the lead time?
A. Sampleneeds 3 days, mass production time needs 5-7 weeks, it
depends on order quantity.
Q. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive.Airline and sea shipping is
also optional.
Q.How about warranty?
A:5 year warranty.
