5kw Solar Energy Storage Battery 48 Volt 100ah Lifepo4 Lithium Ion

Product Categories

Liren Design (Dongguan) Co., Ltd.

Contact Now

5kw Solar Energy Storage Battery 48 Volt 100ah Lifepo4 Lithium Ion

Ask Lasest Price
Brand Name :	Sunica
Model Number :	01
Certification :	ce
Price :	USD 400- 10000 / pieces
Payment Terms :	T/T, L/C, D/A, D/P
Supply Ability :	100000 packs per year
Delivery Time :	7-20 working days

Add to Cart

Product Details
Company Profile

5kw Solar Energy Storage Battery 48 Volt 100ah Lifepo4 Lithium Ion

5kw Solar Energy Storage Battery Lithium Ion Batteries 48V100ah Lifepo4

Model	TP48100(4U)
Nominal voltage(V)	51.2
Nominal capacity(Ah)	100
Nominal energy (Wh)	5120
Maximum charging voltage(V)	58.4
Max. charging current(A)	100
Charging method	CC/CV
Max Continuous Discharge Current(A)	100
Maximum peak discharge current @10sec(A)	110
Max. load power(W)	4500
Discharge cut-off voltage(V)	40
Charging temperature(℃)	0~+50
Discharge temperature(℃)	-20~+60
Operating humidity:	<95%R.H
Operating humidityCycle times(25℃,0.5C,80%DOD)	>2000
Battery combination mode	15S3P
Terminal specification	KF57-2P*2
Protection class	IP54
Dimension(mm)	442480177 mm
Reference weight(kg)	45
Communication mode	232/485/CAN

This Lithium-Ion Battery has a long lifespan of 6 000 cycles at 80%
depth of discharge at 25°C. In addition, the batteries can support
up to 15 batteries in parallel for expansion. The batteries are set
to sleep mode (off) during transportation and storage to reduce
loss of capacity. has the following remarkable characteristics:

mounted lifepo4 battery

Support OEM / ODM brand

support pack 48v 100ah-200ah rack mounted lifepo4 battery

Variety powerpole connector for you to choose

RS485 / RS232 / CAN communication or without communication

Special metal case size

Support Connected in parallel mode for expansion (to store more
energy)

Plug and Play, easy to connect and operate

FAQ:Q.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.Q. What about the lead time?
A. Sampleneeds 3 days, mass production time needs 5-7 weeks, it
depends on order quantity.
Q. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the
different part numbers. 1~10pcs sample order is available. Low MOQ,
1pc for samplechecking is available.
Q. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive.Airline and sea shipping is
also optional.
Q.How about warranty?
A:5 year warranty.
