15W Smart Solar Inverter Blue Smart Hybrid Solar Inverter

Ask Lasest Price
Brand Name :	ONE INVERTER
Model Number :	SN-350W-JWY
Price :	USD 65- 70 / Piece
Payment Terms :	T/T
Supply Ability :	1000 piece per month
Delivery Time :	7-20 working days

Add to Cart

Product Details
Company Profile

15W Smart Solar Inverter Blue Smart Hybrid Solar Inverter

Product Paramenters
MODEL	SN-351	SN-501	SN-601	SN-801	SN-102	SN-122
RATED POWER	350W	500W	600W	800W	1000W	1200W
SURGE POWER	1050W	1500W	1800W	2400W	3000W	3600W
INPUT
VOLTAGE	220VAC
SELECTABLE VOLTAGE RANGE	145-265VAC
FREQUENCY RANGE	50HZ/60HZ±5HZ
OUTPUT
AC VOLTAGE REGULATION(BATT. MODE)	(DC BATT.MODE)220VAC±3%
TANSFER TIME	≤8ms
WAVE FORM	PURE SINE WAVE
BATTERY
BATTERY VOLTAGE	12V/24V
FLOATING CHARGE VOLTAGE	13.8V(12V)/27.6V(24V)
OVERCHARGE PROTECTION	17V(12V)/34V(24V)
SOLAR CHARGE & AC CHARGER
MAXIMUM PV ARRAY OPEN CIRCUIT VOLTAGE	150VDC
MAXIMUM PV ARRAY POWER	30V(12V)/50V(24V)
STANDBY POWER COMSUMPTION	15W
MAXIMUM AC CHARGE CURRENT	15A
MAXIMUM SOLAR CHARGE CURRENT	20A				30A
MAXIMUM CHARGING CURRENT	35A				45A
PHYSICAL
DIMENSION,DWH(MM)	345315187MM
G.W.(KGS)	8.3	9	9.1	9.8	10	10.3
ENVIRONMENT
HUMIDITY	0~95%(NO CONDESNSATION)
OPERATING TEMPERATURE	0~60℃
STORAGE TEMPERATURE	0~60℃
*PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT FURTHER NOTICE

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
		FOB
		CFR(C&F)	30% T/T in advance, paid the balance against copy of B/L
		CIF
	L/C	L/C amount above 50,000 usd, we can accept L/C at sight
	West Union	Amount lower than 5000usd
Delivery Time	7-10 working days after receiving payment (should be decided according to quantity)

FAQ.

Q:1. Are you manufacturer or trading company? A:We are manufacturer
with SGS factory audit. Q:2. What certificates do you have?
A:We have CE, SGS,TUV, IEC, and ISO so far. Q:3. How about your
warranty? A:15-25 years guarantee. Q:4. Do the panels all include
cables and connectors? A:Yes, all include cables and connectors.
Q:5. Can you produce the solar panels according to our drawing?
A:Yes, we provide both OEM and ODM services. Q:6. Can you provide a
complete set of solar accessories and solutions? A: Yes, our
company can provide complete construction and installation
services. We have our own construction team in Australia. Australia
is
mainly responsible for local construction and technical remote
services.
